HMT DIN is a serie of axial piston motors particularly suitable for mobile hydraulics. HMT DIN is of the bent-axis type with spherical pistons.
The design gives a compact motor with few moving parts, high starting torque and high operational reliability. It covers the entire displacement range 12- 130 cm3/rev. with max. pressure 400 bar.
It’s high level of reliability is due to the choice of materials, hardening methods, surface structures and the quality assured manufacturing process.
PRODUCT BENEFITS
Smooth operation over the entire speed range.
High efficiency.
Suitable for applications with high angular accelerations due to its high rotary stiffness (timing gear).
| Specification | Value |
|---|---|
| Displacement (Cm³/Rev) | 47.1 |
| Operating Pressure | (Bar) |
| Max. Intermittent (Bar) | 400 |
| Max. Continuous (Bar) | 350 |
| Revolutions | (Rev/Min) |
| Max. Intermittent (Rev/Min) | 2500 |
| Max. Continuous (Rev/Min) | 2000 |
| Min. Continuous (Rev/Min) | 300 |
| Power | (kW) |
| Max. Intermittent (kW) | 65 |
| Max. Continuous (kW) | 52 |
| Other Specifications | Value |
| Starting Torque Theoretical Value (Nm/Bar) | 0.75 |
| Moment of Inertia (x10‾³) (kg m²) | 2.6 |
| Max Intermittent Housing Pressure (Bar) |
5.0 |
| Weight (Kg.) |
13.0 |
| Information About Tehcnical Info |
|---|
| Data concerning RPM is based on maximum permitted peripheral velocity for the tapered roller bearings. Max Intermittent power may depend on application. For further information please contact HIDRAKA. Continuous power data is based on maximum output power without external cooling of the motor housing. Intermittent duty is defined as follows; max 6 seconds per minute, e.g. peak RPM when unloading or accelerating. |
